129D-BB
$9.95
Rocker Switch, 30 Amp DPDT Momentary On-Off-Momentary On
Rocker Switch, 30A DPDT Momentary On-Off-Momentary On
3 position DPDT Momentary On-Off-Momentary On Rocker Switch is rated at 30A @12VDC, 15A @ 125VAC, 10A @ 250VAC. This sealed switch returns to the center off position when the button is released. The contacts are sealed by gaskets to keep out contaminants that cause premature switch failure. This heavy duty switch mounts in a .83 x 1.48 inch hole and it has 1/4 quick connect terminals. Black body and button.
Specifications
- DPDT Momentary On-Off-Momentary On
- Rated at 30A @12VDC, 15A @ 125VAC, 10A @ 250VAC.
- Internal gasket keeps water & dust out of contacts
- .83 x 1.48 inch mounting hole.
- 1/4″ quick connect terminals.
| Weight | 1 oz |
|---|
